Customized Lightning Impulse High Voltage Test System Complete IEC Impulse Generator Solution for Power Transformer, Cable, GIS and High Voltage Test

Model Number : SXCY

Total Impulse Capacitance : 0.0278~0.5 μF

Brand Name : Sansion

Impulse Capacitance : 0.0278~0.5 μF

MOQ : 1 Set

Energy Range : 7.31 ~ 320 kJ

Delivery Time : 30 Working Days

Packaging Details : Plywood Case

Certification : CE/SGS/EMS/ISO 9001

Stage Voltage : ±100 ~ ±200 kV

Payment Terms : T/T,L/C

Voltage Range : ±100kV ~ ±4800kV

Place of Origin : China

Number of Stages : 1 to 24 Stages

Contact Now

Product Description

The Customized Lightning Impulse High Voltage Test System is designed for customers requiring a complete high-voltage impulse testing solution based on specific test objects and laboratory requirements.

Because different transformers, cables, GIS systems and other high-voltage devices have different voltage levels, insulation structures and test requirements, the system can be configured around the customer's actual testing application.

Customizable Configuration

Output voltage range
Generator energy
Number of stages
Waveform types
Positive and negative polarity
Full-wave configuration
Chopped-wave configuration
Switching impulse configuration
Voltage divider range
Measurement accuracy
Control method
Automatic test sequence
Data acquisition
Waveform analysis
Test report format
Remote operation
Laboratory safety interlock

Complete Testing Capability

Depending on the final configuration, the system can support:

Lightning impulse test
Transformer impulse withstand test
Chopped-wave test
Switching impulse test
Cable impulse test
GIS impulse test
Arrester test
Insulator test
High-voltage dielectric testing
Automatic waveform analysis

FAQ

Q: What information is required for customization?

A: Customers should normally provide the test object type, required test voltage, applicable standard, required waveform, energy requirement and laboratory conditions.

Q: Can the system be designed for a complete high-voltage laboratory?

A: Yes. The impulse generator can be integrated with measurement, control, safety interlock and other high-voltage testing equipment as part of a complete laboratory solution.

Q: Can the software be customized?

A: Yes. Data management, waveform analysis, report templates and communication interfaces can be configured according to project requirements.
